SGT-50 GAS TURBINE GENERATOR PACKAGE

Product Brochure:DOWNLOAD

Introduction

Introduction

The list below is SGT-50 GAS TURBINE GENERATOR PACKAGE, which will be provided by seller.

Dongturbo Electric Company Ltd is one of the leading manufacturers and suppliers of sgt-50 gas turbine generator package in China. We warmly welcome you to buy high quality customized products at competitive price from our factory. Contact us for more cheap products.

Basic Information

GTU	SGT-50 GAS TURBINE GENERATOR PACKAGE
Gas Turbine Engine	KG2-3G, Dresser-Rand
Generator	LSA 53.2XL 11/4P, Leroy Somer
Year of Manufacture	November, 2019
Condition	Not installed, not commissioned

The products will be dispatched within 60 days after the contract signed and downpayment received.

Gas Turbine Generator Technical Information

KG2-3G Performance (Typical)
Site conditions	Metric		Imperial
Ambient Temperature	℃	15	℉	59
Altitude	m	0	feet	0
Intake Loss	kPa	0	Inch w.c.	0
Exhaust Loss	kPa	0	Inch w.c.	0
Generator Efficiency	%	0.97	%	0.97
Stack Temperature	℃	90	℉	194
Lower Heating Value	kJ/kg	49000	Btu/lb	21067
Output:
Shaft Power	kW	2015	Hp	2620
Fuel Flow	kW	8031	MM Btu/hr	27.4
Shaft Efficiency	%	25.1	%	25.1
Power Output	kW	1954	hp	2620
Efficiency	%	24.3	%	24.3
Intake Mass Flow	kg/s	9.33	lb/sec	20.6
Exhaust Gas Temperature	℃	587	℉	1089
Exhaust Gas Flow	kg/s	9.49	lb/sec	20.9
Exhaust Gas Heat	kW	5233	MM Btu/hr	17.85
Fuel Flow	kg/h	590	lb/hr	1300
Natural Gas Pressure	bar	12	psig	174
Emissions NO_x/CO(15%O₂)	ppm	24/10	ppm	24/10

Voltage: 10.5 kV Frequency: 50 Hz

The power output, efficiency, exhaust gas temperature, and flow rate of the gas turbine generator set will fluctuate with changes in ambient air temperature.
