1. 1The list below isCAT CG170B-20gas generatorsetsupplyscope, which will be provided by seller
CAT CG170B-20Gas generatorsets | ||
Item |
Supply Scope |
Qty. |
1 |
|
6Sets |
1. 2CAT CG170B-20Gas generatorsetbasic information:
Engine |
CAT CG170B-20 |
Manufacturer |
CAT |
Model |
CG170B-20 |
Fuel |
NG |
Power |
2300KW |
Manufacture time |
2026 |
Efficiency |
43. 9% |
Rotation speed |
1500rpm |
Gas exhausted |
80. 00 kg/s |
Voltage |
400V |
Frequency |
50Hz |
Intake method |
TA |
Cylinder Bore |
170mm |
Stroke |
195mm |
Lube Oil Consumption |
0. 15 g/kWh |
Displacement |
89 dm³ |
Mean Piston Speed |
9. 8 m/s |
Mean Effective Pressure |
21. 5 bar |
Specification | |
L*W*H |
P type:6600×1710×2190 mm;R type:6500×1710×2190 mm |
Dry Weight |
P type:21, 400 kg;R type:17, 980 kg |
2.Delivery time
The products will be dispatched within15DAYSafter the contract signed and downpayment received.
3.Payment terms
4.Quality assurance
Not available, the gas turbine generator sets are sold as"as is"
5.Price validity
This offer will be validated for 10 days.
